Frame Type Rubber Vulcanizing Press Machine with PLC Control Customized Electrical Heating for Rubber Products
Product Summary
Frame Type Rubber Vulcanizing Press Machine PLC Plate Vulcanizing Press Frame Type Rubber Plate Vulcanizing Press For Rubber Products We provide a comprehensive range of rubber vulcanizing hot press machines, with capacities ranging from 15 to 10,000 tons, primarily manufactured as made-to-order ...
Basic Properties
Place of Origin:
Qingdao
Brand Name:
Beishun
Certification:
ISO/CE
Model Number:
XLB-1200X1200X2/400T
Trading Properties
Minimum Order Quantity:
1set
Price:
Negotiable
Payment Terms:
T/T,L/C
Supply Ability:
30sets
Product Description
Frame Type Rubber Vulcanizing Press Machine PLC Plate Vulcanizing Press
Frame Type Rubber Plate Vulcanizing Press For Rubber Products
We provide a comprehensive range of rubber vulcanizing hot press machines, with capacities ranging from 15 to 10,000 tons, primarily manufactured as made-to-order products. Our company offers complete turnkey solutions and technical services, including full machinery installation and production line planning. The Rubber Plate Vulcanizing Press serves as the primary molding equipment for various rubber molding and non-molding products. This versatile machine is also suitable for molding thermosetting plastics, bubble materials, resins, Bakelite, sheet metal, building materials, and other molding applications, featuring simple structure, high pressure capability, wide applicability, and high operational efficiency.
Machine Specifications
| Model | Total Pressure (MN) | Daylight (mm) | Working Layer No. | Piston Stroke (mm) | Main Motor Power (KW) | Overall Dimensions (L x W x H) (mm) |
|---|---|---|---|---|---|---|
| XLB-350*350*2 | 0.25 | 125 | 2 | 250 | 2.2 | 1200*580*1200 |
| XLB-400*400*2 | 0.50 | 125 | 2 | 250 | 2.2 | 1400*500*1400 |
| XLB-600*600*2 | 1.00 | 125 | 2 | 250 | 2.2 | 1880*820*1680 |
| XLB-750*850*4 | 1.60 | 125 | 4 | 500 | 3 | 1730*930*2460 |
| XLB-900*900*2 | 2.5 | 200 | 2 | 400 | 4 | 2345*960*1385 |
| XLB-1200*1200*1 | 3.15 | 300 | 1 | 300 | 4 | 2800*1300*2300 |
| XLB-1300*2000*1 | 5.60 | 400 | 1 | 400 | 8 | 2000*1860*2500 |
| XLB-1500*1500*1 | 8.00 | 800 | 1 | 800 | 16.5 | 2200*2200*4300 |
| XLB-1500*2500*1 | 15.00 | 400 | 1 | 400 | 11 | 3000*2500*3300 |
| XLB-2000*2000*1 | 20.00 | 400 | 1 | 400 | 11 | 3600*3000*3300 |
Key Features
- Advanced Cylinder Design: The cylinder (piston) incorporates optimal seal structure with rational design and reliable functionality. Utilizes high-quality polyurethane seals (not rubber seals) that are oil-resistant and aging-resistant. Features double seal structure for easy replacement and protection.
- Automated Control System: Comprehensive automation including automatic mold closing, automatic exhausting, automatic heating with temperature stabilization, automatic vulcanization timing, automatic alarm system, and automatic mold opening.
- Digital Temperature Control: Vulcanizing temperature can be precisely set and displayed on digital display for accurate process control.
- PLC Time Setting: Vulcanizing time can be directly programmed through the PLC screen. When set time is reached, machine automatically alarms and opens the mold.
- High-Quality Pillar Construction: Pillars manufactured from premium #45 steel, enhanced through quenching and tempering processes to significantly improve hardness, wear resistance, and abrasive resistance.
- Robust Frame Structure: Top beam and bottom plate constructed from high-quality Q-235A ductile iron welding. Post-welding processing includes artificial vibration or high-temperature aging treatment to eliminate internal stress and prevent deformation.
- Durable Plunger Design: Plunger crafted from LG-P cold hard alloy steel with surface hardness of HRC 60-70 and chilled layer depth of 8-15mm, ensuring exceptional wear resistance and extended service life.
Product Details
Highlight:
Frame Type Rubber Vulcanizing Press Machine
,Rubber Vulcanizing Press Machine PLC
,PLC Plate Vulcanizing Press
Heating Way:
Electrical / Oil System
Control Method:
PLC Control
Customized:
Customized
Voltage:
Customer Request
Application:
Vulcanizing To Be Final Product,Vulcanizing Rubber Products
After-Sales Service Provided:
Engineers Available To Service Machinery Overseas,Video Technical Support
