Full Automatic Rubber Vulcanizing Press Machine with 45 Steel Heating Plates and Cast Steel Cylinder for Final Product Vulcanizing

All Category

Rubber Vulcanizing Press Machine

Batch Off Rubber Cooling Machine

Motorcycle Tyre Making Machine

Conveyor Belt Vulcanizing Machine

Rubber Machine Parts

Mr. Alexey Pan

info@beishunchina.com

0086 15154222850

Contact Now

Full Automatic Rubber Vulcanizing Press Machine with 45 Steel Heating Plates and Cast Steel Cylinder for Final Product Vulcanizing

Brand Name:	Beishun
Model Number:	XLB-1500X1500X1/1200T
MOQ:	1set
Price:	Negotiable
Packaging Details:	Wooden box/20GP/40GP
Payment Terms:	T/T,L/C

Detail Information

Product Description

Detail Information

Place of Origin:

Qingdao

Certification:

ISO/CE

Heating System:

Oil Or Steam Or Electrical

Structure:

Column Or Frame

Control Method:

PLC Control

Heaing Plates:

#45 Steel

Cylinder Material:

Cast Steel

Application:

Vulcanizing To Be Final Product,Vulcanizing Rubber Products

Supply Ability:

30sets

Highlight:

Rubber Vulcanizing Machine Full Automatic ISO

Technical Rubber Vulcanizing Machine

Full Automatic Plate Vulcanizing Press

Product Description

Technical Rubber Vulcanizing Machine Full Automatic Plate Vulcanizing Press

Advanced Technical Rubber Vulcanizing Press With Full Automatic Control System

We provide a wide range of rubber vulcanizing hot press machines, ranging from 15 to 10,000 tons, mostly made-to-order products. Our turnkey solutions include complete machinery installation and production line planning services. The Rubber Plate Vulcanizing Press is the primary molding equipment for various rubber products and is also suitable for thermosetting plastics, resins, sheet metal, building materials, and other molding applications. It features a simple structure, high pressure capacity, wide applicability, and high efficiency.

Machine Specifications

Model	Total Pressure (MN)	Daylight (mm)	Working Layer No.	Piston Stroke (mm)	Main Motor Power (KW)	Overall Dimensions (L x W x H) (mm)
XLB-350×350×2	0.25	125	2	250	2.2	1200×580×1200
XLB-400×400×2	0.50	125	2	250	2.2	1400×500×1400
XLB-600×600×2	1.00	125	2	250	2.2	1880×820×1680
XLB-750×850×4	1.60	125	4	500	3	1730×930×2460
XLB-900×900×2	2.5	200	2	400	4	2345×960×1385
XLB-1200×1200×1	3.15	300	1	300	4	2800×1300×2300
XLB-1300×2000×1	5.60	400	1	400	8	2000×1860×2500
XLB-1500×1500×1	8.00	800	1	800	16.5	2200×2200×4300
XLB-1500×2500×1	15.00	400	1	400	11	3000×2500×3300
XLB-2000×2000×1	20.00	400	1	400	11	3600×3000×3300

Key Features

The cylinder (piston) features an advanced seal structure with high-quality polyurethane seals (not rubber) that are oil-resistant and aging-resistant. Our double-seal design is easy to change and maintain.
Fully automatic control system including automatic mold closing, exhaust, heating with temperature stability, timed vulcanization, alarm system, and mold opening.
Digital display for precise vulcanizing temperature setting and monitoring.
PLC-controlled vulcanizing time setting with automatic alarm and mold opening when cycle completes.
Pillars constructed from high-quality #45 steel, hardened through quenching and tempering for superior hardness, wear resistance, and durability.
Top beam and bottom plate welded from premium Q-235A ductile iron, stress-relieved through vibration or high-temperature aging to prevent deformation.
Plunger made from LG-P cold hard alloy steel with surface hardness of HRC 60-70 and chilled layer depth of 8-15mm for extended service life.

Frequently Asked Questions

What is the delivery time for the Batch Off Rubber Cooling Machine?

As a custom-designed machine, production typically takes 35 to 45 days from engineering design to completion.

What quality control measures does your factory implement?

We maintain strict quality control throughout production. Every machine undergoes complete assembly and thorough testing before shipment.

What is the machine's quality guarantee period?

We provide a two-year quality guarantee and use world-renowned brand components to ensure optimal performance.

Do you provide overseas installation and commissioning services? How long does it take?

Yes, we offer international service and technical support (customer covers installation costs). Small machines typically require 3-5 days, while large plants need about 30 days.

How can I trust you'll deliver the machine as ordered?

We provide regular production updates and photos during manufacturing. Our company culture emphasizes innovation, quality, integrity, and efficiency, with many successful partnerships with global rubber manufacturers.

How can we visit your facility?

We're located in Qingdao City, Shandong province, China (Qingdao Liuting Airport). We provide airport pickup services for visiting clients.
