Water Cooling Conveyor Belt Vulcanizing Machine Automatic Conveyor Belt Jointing Machine

Rubber Conveyor Belt Splicing Vulcanizing Press Machine For Splicing Rubber Conveyor Belts

Application:

The Conveyor Belts Splicing Vulcanizing Press is dependable, lightweight and portable machine, which is widely used in the field of jointing of canvas, nylon, steel cord conveyor belt at spot in the field of metallurgy,mining, power plants, ports, building materials, cement, coal mine, chemical industry, etc. Heating plates are available for rhombic, rectangular and modular type (two or more sets of heating plates together).

Machine specification of Conveyor Belt Splicing Vulcanizing Press

Conveyor Belt Splicing Vulcanizing Press Features:

1. The electric control box of hot splicing press is made of industrial grade aluminum alloy,small volume and light weight. Three-phase source of power supply.

2. Water press system can supply stable press.

3. Fast heating, steady heating temperature.

4. Equipped with auto electric control,easy to operate.

5. Degree of the heating platen: 22°/17°/ 20° (rectangle and other degree is optional)

6. High pressure water pump, adopted three cylinder plunger pump driven by single-phase machine,with the characteristics of compact structure, small volume, reliable, maintenance friendly.

7. Sturdy heating plate with hydraulic pressure system ensures temperature unifor-mity, high pressure can reach Max.2.0 MPa ;Heating plate including air or water cooling.

8. Time of heat preservation for vulcanizing could be adjusted according to thickness of the rubber belts;

9. Splicing length of rubber conveyor belt for vulcanizing jointing could be connected together by single or several pieces if necessary;

10. Rubber conveyor belt as well as tension in kilogram required for vulcanizing jointing when ordering products.

11.Users could order spare electric pumps additionally according to requirements. Model for Choice( or Just me your belt size, belt type)

12.Customization/OEM: Different heating platen size and combination

Conveyor Belts Splicing Vulcanizing Press Technical Specification

1. Vulcanization pressure: 1.0-2.0Mpa or customized;

2. Vulcanization temperature: 145 °C;

3. Surface temperature difference of vulcanized plate: ± 3 °C;

4. Heating-up time (145 °C): ≤30 mins;

5. Power supply voltage: 220V to 1140V; 50/60 Hz; 3Ph;

6. Output power of Electronic Control Box: 23.3 KW;

7. Temperature adjustment range: 0-200 °C;

8. Timing adjustment range: 0-99 min;

9. After the pressurization of 0.8 MPa, the gap between upper and lower heating plate is not more than 0.4 mm.

10. Power Voltage: 380V. 660V. 480V. 440V. 415V. 400V or 220V.
