Rubber Vulcanizing Press Machine

2RT/4RT Single And Double Station Electric Heating Rubber Vulcanizing Molding Machine For Rubber 0-25MPa Pressure Range

All Category

Rubber Vulcanizing Press Machine

Batch Off Rubber Cooling Machine

Motorcycle Tyre Making Machine

Conveyor Belt Vulcanizing Machine

Rubber Machine Parts

Mr. Alexey Pan

info@beishunchina.com

0086 15154222850

Contact Now

2RT/4RT Single And Double Station Electric Heating Rubber Vulcanizing Molding Machine For Rubber 0-25MPa Pressure Range

Brand Name:	Beishun
Model Number:	XLB-800*800
MOQ:	1set
Price:	Negotiable
Packaging Details:	Wooden box/container
Payment Terms:	T/T,L/C

Detail Information

Product Description

Detail Information

Place of Origin:

Qingdao，China

Certification:

ISO/CE/SGS

Temperature Range:

0-300℃

Control System:

Certificate:

Voltage:

Customized

Heating Mode:

Electric Heating

Vulcanizing Time:

0-999s

Cylinder Stroke:

200mm

Material:

Steel

HS Code:

8477800000

Mitushibi , Siemens .

Supply Ability:

30sets/month

Highlight:

Electric Heating Rubber Vulcanizing molding Machine

0-25MPa Rubber Vulcanizing molding Machine

Double Station Rubber Vulcanizing Molding Machine

Product Description

2RT/4RT Single and double station Electric Heating Rubber Vulcanizing molding Machine for Rubber 0-25MPa Pressure Range

Product Description:

This series of plate vulcanizing machine is a special molding equipment for rubber industry. The heating method adopts electric heating (steam or oil heating), and the power adopts high combination pump as the oil method to reduce the power loss of the equipment.

The electrical control adopts advanced PLC control technology, which can realize automatic control, automatic operation mold, automatic heating control and other processes. And can realize automatic deflating, automatic closing, opening, pushing, top die, so as to ensure product quality and high efficiency.

In addition, according to the technical requirements of customers, we can customize a variety of four-column, frame, workbench, workbench and other plate vulcanization machines.

Features:

1. Rubber mixing equipment: kneader, bucket,mixing mill, bale cutter
2. Rubber vulcanizing machine: Four-column press, Frame press, E-type press, tire and tube press, Belt vulcanizing press.
3. Automatic and semi-automatic waste tire recycling equipment
4. Rubber calendaring machine: 2 roll, 3 roll, 4 roll calender, calendaring line
5. Rubber extruding equipment: Hot feed extruder,cold feed extruder, belt extrudingand calendering line .
6. Reclaimed rubber production line: XKJ-450 , XKJ-480 Rubber reining mill.
7. Paper roll cutting machine.
Ouli machines have been exported to more than 20 countries such as America, Canada, Australia, Southeast Asia, Middle East,Brazil.
We warmly welcome customers visit our factory and technology discussion is highly appreciated.

Technical Parameters:

Parameter/model	100 Ton	150 Ton	200 Ton	250 Ton	300 Ton	350 Ton	400 Ton	500 Ton
Clamping Force(T)	100	150	200	250	300	350	400	500
Plate Size(mm)	400*400	450*460	560*560	650*600	650*650	750*700	850*850	1000*1000
Pistion Stroke(mm)	250	250	250	250	280	300	300	300
Cylinder Diameter(mm)	250	300	355	400	450	475	500	560
Main Motor Power(KW)	12	17	22	34	34	43	48	72
Type of mold opening	Track-Mold-Open
Weight(KG)	4500	5500	7000	9000	11000	15000	17500	21500
Length(mm)	2650	3200	3650	4200	2360	2930	2500	3750
Width (mm)	2000	2700	2600	3300	1650	2350	2630	2700
Height(mm)	2000	2500	2610	3300	1850	2100	3460	2800

Keywords: Rubber Heat Press Machine, Rubber Molding Vulcanizing Press, Rubber Plate Vulcanizing Machine

Applications:

The Rubber Vulcanizing Press Machine is specifically designed to operate in a range of industries, including automotive, construction, and manufacturing. It is perfect for vulcanizing rubber products such as rubber tires, rubber mats, and other rubber products. The machine has a cylinder stroke of 200mm, a voltage of 220V/380V/400V/440/, and a pressure range of 0-25MPa. The control system is PLC, which makes it easy to operate and monitor the machine's performance.

The Rubber Tire Vulcanizing Press is ideal for the automotive industry, where it can be used to produce high-quality rubber tires that meet industry standards. The machine's precise pressure control system ensures that the tires are vulcanized to the required specifications, resulting in high-quality and durable products that can withstand harsh environments and heavy use.

The Rubber Mat Vulcanizing Press is perfect for the construction industry, where it can be used to produce high-quality rubber mats that can be used for flooring and other applications. The machine's pressure control system ensures that the mats are vulcanized to the required specifications, resulting in high-quality and durable products that can withstand heavy use and harsh environments.

In conclusion, the Beishun Rubber Vulcanizing Press Machine is a versatile and high-quality product that is designed for a variety of applications. With its precise pressure control system, it is ideal for vulcanizing rubber products such as rubber tires and mats. The machine is easy to operate, and its PLC control system ensures that performance is monitored and optimized for efficient production. With a delivery time of 45 days and a supply ability of 30 sets per year, this machine is a reliable and cost-effective investment for any business in need of high-quality rubber vulcanization equipment.

Packing and Shipping:

Product Packaging:

The rubber vulcanizing press machine is securely packed and shipped in a wooden crate to prevent any damages during transportation.
All necessary components and accessories are included in the package.
Clear and comprehensive instruction manual is provided to assist with the assembly and operation of the machine.

Shipping:

The rubber vulcanizing press machine is shipped via a reputable carrier service.
The shipping cost is calculated based on the destination and weight of the package.
The estimated shipping time will be provided to the customer upon order confirmation.
A tracking number will be provided to the customer once the package is shipped
