XLB-400×400/0.8MN,Rubber Gasket Curing Press machine / Hot Molding Press

XLB-400×400/0.8MN,Rubber Gasket Curing Press machine / Hot Molding Press

Brand Name:	Beishun
Model Number:	XLB-400×400/0.5MN
MOQ:	1set
Price:	Negotiable
Payment Terms:	T/T
Supply Ability:	10sets/45day

Detail Information

Product Description

Detail Information

Place of Origin:

Qingdao

Certification:

ISO9001/CE

Customize:

Customized

Frame Material:

High-strength Steel

Plunger Diameter:

250mm

Voltage:

As Your Requirement

Cylinder Stroke:

500mm

Plate Size:

Customizable, E.g., 500mm X 500mm

Auto:

Automatic

Plate Daylight:

200mm

Working Layers:

Customized

Production Products:

Rubber Gasket

Piston Stroke:

250mm

Apply Voltage:

380V 50HZ Or Customized

Clamping Pressure:

50ton

Operating Voltage:

380V 50HZ 3Phase Or Customized

Packaging Details:

wooden box

Highlight:

Rubber Gasket Curing Press machine

Hot Molding Press 0.8MN capacity

400×400 Rubber Vulcanizing Press

Product Description

XLB-400×400/0.8MN Rubber Gasket Curing Press Machine / Hot Molding Press

The XLB-400×400/0.8MN Rubber Gasket Curing Press Machine is a precision hot molding press designed for laboratory and small-scale production applications. This fully automatic flat plate vulcanizing machine provides reliable pressure and temperature control for rubber material processing.

Machine Definition & Working Principle

This small flat plate vulcanizing machine, also known as a hot pressing molding machine, places raw materials in a mold and applies rated pressure and temperature to shape rubber materials. Through controlled heating cycles, materials reach their vulcanization point or melting point, producing molded components with specific physical properties.

The working process involves placing materials between upper and lower electric heating plates within the mold. Under intelligent constant temperature conditions, pressure is applied to shape materials, providing reliable reference data for factory batch production.

Primary Application Fields

Material Research & Development: Used by research institutions to develop new rubber materials and conduct physical/chemical performance testing
Product Trial Production: Enables small and medium enterprises to explore new product manufacturing processes and identify production issues
Educational Training: Provides practical experience for university students and vocational training programs
Industrial Applications: Automotive parts, aerospace seals, equipment components, electronic product protective covers, and cable insulation layers

Technical Features & Automation

The 20-50 ton fully automatic laboratory vulcanizing machine represents advanced mechanical manufacturing with high-performance automation capabilities. Its sophisticated control systems and mechanical design enable complete vulcanization process automation, improving efficiency while reducing labor requirements.

Key Operational Benefits

Wide vulcanization temperature and pressure ranges accommodate diverse material requirements
Intelligent touch screen interface for simplified parameter input and operation
Multiple integrated safety protection systems ensure process reliability
High-quality heating plates and insulation layers maintain temperature uniformity and stability

This vulcanizing machine enhances laboratory capabilities with its practical design, efficiency improvements, and quality assurance features. Whether in research laboratories or production environments, it delivers consistent performance for rubber material processing applications.

XLB-400×400/0.8MN Rubber Gasket Curing Press Machine - Laboratory vulcanizing equipment with control panel and heating plates
