720T ISO2000 Hydraulic Vulcanizing Machine with 44.4kg/cm² Pressure Automatic Rubber Moulding Press
Product Summary
720T Automatic Hydraulic Vulcanizing Machine ISO2000 Hydraulic Rubber Moulding Machine 720T Automatic PLC Control Rubber Tread Vulcanizing Press Machine Rubber Vulcanizing Press Machine applies to all kinds of rubber (natural rubber, EPDM rubber, NBR rubber, synthetic rubber, silicone rubber etc.) ...
Basic Properties
Place of Origin:
Qingdao
Brand Name:
Beishun
Certification:
ISO/CE
Model Number:
XLB-450X3600X5/720T
Trading Properties
Minimum Order Quantity:
1set
Price:
Negotiable
Payment Terms:
T/T,L/C
Supply Ability:
30sets
Product Description
720T Automatic Hydraulic Vulcanizing Machine ISO2000 Hydraulic Rubber Moulding Machine
720T Automatic PLC Control Rubber Tread Vulcanizing Press Machine
Rubber Vulcanizing Press Machine applies to all kinds of rubber (natural rubber, EPDM rubber, NBR rubber, synthetic rubber, silicone rubber etc.) vulcanizing and compression molding.
Applications:
- Rubber seals
- O-ring
- Oil seal
- Auto parts
- Rubber crash pad
- Rubber air spring
- Key board
- Medical rubber parts
- Rubber bottle stopper
- Silicone wrist band
- Water-stop tape
- Bridge support/bridge bearings
- Rubber cable
- Blankets
- Hand cart tires
- Rubber wheels
- Tractor tires
- Agricultural tires
- Cycle tires
- Electronics insulators
Technical Specifications
| Model | Total Pressure (MN) | Daylight (mm) | Working Layer No. | Piston Stroke (mm) | Main Motor Power (KW) | Overall Diameter (L x W x H) (mm) |
|---|---|---|---|---|---|---|
| XLB-350*350*2 | 0.25 | 125 | 2 | 250 | 2.2 | 1200*580*1200 |
| XLB-400*400*2 | 0.50 | 125 | 2 | 250 | 2.2 | 1400*500*1400 |
| XLB-600*600*2 | 1.00 | 125 | 2 | 250 | 2.2 | 1880*820*1680 |
| XLB-750*850*4 | 1.60 | 125 | 4 | 500 | 3 | 1730*930*2460 |
| XLB-900*900*2 | 2.5 | 200 | 2 | 400 | 4 | 2345*960*1385 |
| XLB-1200*1200*1 | 3.15 | 300 | 1 | 300 | 4 | 2800*1300*2300 |
| XLB-1300*2000*1 | 5.60 | 400 | 1 | 400 | 8 | 2000*1860*2500 |
| XLB-1500*1500*1 | 8.00 | 800 | 1 | 800 | 16.5 | 2200*2200*4300 |
| XLB-1500*2500*1 | 15.00 | 400 | 1 | 400 | 11 | 3000*2500*3300 |
| XLB-2000*2000*1 | 20.00 | 400 | 1 | 400 | 11 | 3600*3000*3300 |
Key Features
- High speed open/close molds, high production efficiency
- Automatic in/out mold and ejector device, low labor strength
- Optional normal valve or proportional valve, advanced oil way matching, reduce energy consumption
- The electric system adopts PLC programming control, which is easy to operate
- Touch screen operation of pressure and temperature for user-friendly control
Machine Structure
- 4-columns structure and frame structure, as a below pressing type (upwards)
- Heating plate opens by the self-weight of the hot plate, platform and plunger
- Plate size, piston stroke and total pressure can be customized
- Available with manual-pull mold or automatic hydraulic-pull mold options
- Three control methods: manual, semi-automatic, and full automatic
- Fast speed mould-closing with high production efficiency
- Low locking speed to protect mould
- Oil cylinder made of nodular cast iron for improved compressive strength and wear resistance
Product Details
Highlight:
Rubber Vulcanizing Press Machine, Rubber Tread Vulcanizing Press Machine
Clamping Force:
720T
Product Name:
Rubber Vulcanizing Press Machine
Unit Area Pressure:
44.4kg/cm²
Control Method:
PLC Control
Plunger Material:
Chilled Cast Iron
