PLC Control 800T Hydraulic Vulcanizing Press Machine Customized for Rubber Moulding

PLC Control 800T Hydraulic Vulcanizing Press Machine Customized for Rubber Moulding

Brand Name:	Beishun
Model Number:	XLB-1500X2000X1/1200T
MOQ:	1set
Price:	Negotiable
Payment Terms:	T/T,L/C
Supply Ability:	30sets

Detail Information

Product Description

Detail Information

Place of Origin:

Qingdao

Certification:

ISO/CE

Type:

PLC Control

Heating Way:

Electrical / Oil System

Customized:

Customized

Voltage:

Customer Request

After-sales Service Provided:

Engineers Available To Service Machinery Overseas,Video Technical Support

Application:

Vulcanizing To Be Final Product,Vulcanizing Rubber Products

Packaging Details:

Wooden box/20GP/40GP

Highlight:

PLC Control Belt Vulcanizing Machine

Belt Vulcanizing Machine 100T

100T Hydraulic Press For Rubber Moulding

Product Description

PLC Control Belt Vulcanizing Machine 800T Hydraulic Press For Rubber Moulding

Automatic PLC Control Platen Compression Rubber Vulcanizing Press

Professional hydraulic press machine designed for rubber product vulcanization with advanced PLC control system.

Applications

We provide comprehensive rubber vulcanizing hot press solutions ranging from 15 to 10,000 tons, primarily custom-made to meet specific requirements. Our turnkey services include complete machinery installation and production line planning.

This versatile rubber vulcanizing press machine is suitable for:

All types of vulcanizing molds
Rubber and plastic mold products
Non-mold products

Machine Specifications

Model	Total Pressure (MN)	Daylight (mm)	Working Layer No.	Piston Stroke (mm)	Main Motor Power (KW)	Overall Dimensions (L x W x H) (mm)
XLB-350×350×2	0.25	125	2	250	2.2	1200×580×1200
XLB-400×400×2	0.50	125	2	250	2.2	1400×500×1400
XLB-600×600×2	1.00	125	2	250	2.2	1880×820×1680
XLB-750×850×4	1.60	125	4	500	3	1730×930×2460
XLB-900×900×2	2.5	200	2	400	4	2345×960×1385
XLB-1200×1200×1	3.15	300	1	300	4	2800×1300×2300
XLB-1300×2000×1	5.60	400	1	400	8	2000×1860×2500
XLB-1500×1500×1	8.00	800	1	800	16.5	2200×2200×4300
XLB-1500×2500×1	15.00	400	1	400	11	3000×2500×3300
XLB-2000×2000×1	20.00	400	1	400	11	3600×3000×3300

Machine Features

4-columns structure and frame design with below pressing type (upwards operation)

Heating plate opens automatically via self-weight of hot plate, platform and plunger

Customizable plate size, piston stroke and total pressure to meet specific requirements

Optional manual-pull mold and automatic hydraulic-pull mold systems

Three control methods: manual and automatic operation modes

Fast mold-closing speed with high production efficiency

Low locking speed to protect mold integrity

Nodular cast iron oil cylinder for enhanced compressive strength and wear resistance

Multiple small oil cylinders ensure uniform vulcanization pressure distribution

Superior vulcanization quality compared to traditional bottom-mounted flat presses

Advanced Configuration

Advanced PLC control system with programmable working parameters

Automated functions: lifting, mold open/close, air exhausting, pressure filling

Vulcanizing timing and alarm functions with manual/auto control switching

High-quality hydraulic components imported from Taiwan

FCD 50 ductile cast iron body casting with high tensile strength after aging passivation

Medium carbon steel columns with hardness up to HRC55-58

Three-stage winding cartridge heaters with nichrome wire, non-rust construction

Japanese Sakagami brand oil seals for wear resistance and oil tightness

Premium electrical components from Schneider or Mitsubishi for stable performance

Optional mold push-pull device for improved efficiency and labor savings

Precision temperature control system for consistent product quality
