Hydraulic Automatic Rubber Cutting Machine with 8T Cutting Force for Bale Cutter Applications
Product Summary
Vertical Rubber Cutting Machine Hydraulic Bale Cutter Machine Auto Control High Efficiency Bale Cutters Cutter Rubber Cutting Machine Application This rubber cutter is primarily used for cutting natural rubber, synthetic rubber, and other plastic materials. It is particularly suitable for installati...
Basic Properties
Place of Origin:
Qingdao
Brand Name:
Beishun
Certification:
ISO/CE
Model Number:
XQL-80
Trading Properties
Minimum Order Quantity:
1set
Price:
Negotiable
Payment Terms:
T/T,L/C
Supply Ability:
30sets
Product Description
Vertical Rubber Cutting Machine Hydraulic Bale Cutter Machine
Auto Control High Efficiency Bale Cutters Cutter Rubber Cutting Machine
Application
This rubber cutter is primarily used for cutting natural rubber, synthetic rubber, and other plastic materials. It is particularly suitable for installation near rubber mixers to cut small pieces of rubber.
Single Knife Vertical Rubber Cutter Features
- Utilizes high-hardness, high-precision circular knife cutting with pneumatic feed and pneumatic tailstock (featuring over-pressure protection)
- Cutting spindle with replaceable steering to accommodate various cutting methods
- Optional increased feeding diameter to ø300mm with additional drive motor and reducer at circular knife components
- Precision linear guide bearings in knife seat ensure stable cutting and superior finished edge quality, ideal for large-diameter bubble surface materials
- Optional sword-type flat knife slitting structure for manual cutting operations with PE hose protection to prevent blade damage
- Slitting length determined by hexagon positioning shaft with six basic slitting width settings and multiple accurate cutting width locations
Machine Specifications
| Model | XQL-80 | XQL-160 | XQL-200 |
|---|---|---|---|
| Knife Width (mm) | 660 | 1000 | 1500 |
| Knife Stroke (mm) | 680 | 680 | 1200 |
| Diameter of the Piston (mm) | 150 | 150 | 600 |
| Time Taken by the Stroke (s) | 16-25 | 16-25 | 16-25 |
| Motor Power (KW) | 5.5 | 7.5 | 11 |
| Overall Dimension (mm) (L*W*H) | 1900*720*2580 | 2240*720*2580 | 2860*1500*3560 |
| Machine Weight (Kgs) | 1000 | 1600 | 2600 |
| Remarks | Can be equipped with working table according to customers' requirements | ||
Frequently Asked Questions
Delivery time of the Batch Off Rubber Cooling Machine?
This is a specially designed machine according to your specific requirements. From engineering design to production completion, it typically requires 35 to 45 days.
What does your factory do regarding quality control?
We implement comprehensive quality control measures throughout the entire production process. Every machine undergoes full assembly and rigorous testing before shipment.
What's the machine quality guarantee?
We provide a two-year quality guarantee. Our machines incorporate world-renowned brand components to ensure optimal performance and reliability.
Are you able to give installation and commissioning overseas? How long time will it take?
Yes, we offer overseas installation services and technical support. Customers are responsible for installation costs. Small machines typically require 3-5 days, while larger plants may take approximately 30 days.
How can I trust you to deliver the right machine as I ordered?
We guarantee delivery of high-quality machines as specified in your order. During production, we provide regular updates including production schedules and progress photos. Our company culture emphasizes innovation, quality, integrity, and efficiency, and we maintain partnerships with renowned rubber production manufacturers worldwide.
How can we go to your side?
We are located in Qingdao City, Shandong province, China. The nearest airport is Qingdao Liuting Airport, and we provide airport pickup services for our clients.
Product Details
Highlight:
660mm Vertical Rubber Cutting Machine
,Rubber Bale Cutting Machine
,Hydraulic Bale Cutter Machine
Power Source:
Hydraulic
Cutting-Off Force(T):
8
Core Components:
Motor, Knife
Key Selling Points:
Automatic
Applicable Industries:
Manufacturing Plant
Voltage:
Customer Request
