Quality Mine screen rubber vulcanizing press machine to Automatic Two-layer factory

Mine screen rubber vulcanizing press machine to Automatic Two-layer

Name: Mine screen rubber vulcanizing press machine to Automatic Two-layer
Brand: Qingdao Beishun Environmental Protection Technology Co.,Ltd
SKU: XLB-1500×2000X2
Price: 1000000 USD
Availability: InStock

Product Summary

Mine screen rubber vulcanizing press machine to Automatic Two-layer 1. Qingdao Beishun frame vulcanization machine is designed and manufactured according to customer's product size. It requires customers to provide plate size, plate daylight, piston stroke, working hydraulic pressure, etc., for our ...

Basic Properties

Place of Origin: Qingdao

Brand Name: Beishun

Certification: ISO/CE

Model Number: XLB-1500×2000X2

Trading Properties

Minimum Order Quantity: 1set

Price: Negotiable

Payment Terms: T/T,L/C

Supply Ability: 30sets

Tags:

vulcanizing press machine

rubber press machine

rubber molding machine

Product Description

Mine screen rubber vulcanizing press machine to Automatic Two-layer

1. Qingdao Beishun frame vulcanization machine is designed and manufactured according to customer's product size. It requires customers to provide plate size, plate daylight, piston stroke, working hydraulic pressure, etc., for our production of special plate, mine special screen, vulcanization machine.

1)20 years of rubber vulcanization machinery manufacturing and export.
2) Delivery within 30 days.
3) Safe wood or plywood crate packing.
Full transit insurance.
5) Products are sold to Russia, Turkey, Mexico, Bulgaria, India and other 126 countries.
6) Qingdao Beishun one-stop rubber machinery solution
7) PLC Siemens control system.
8) Customers can choose and customize according to their needs.
9) New design concept, strong technical force and advanced manufacturing process to ensure that each press can produce a press to meet the special requirements of customers.
10) CE, SGS, ISO9001:2008 certification.
11)PLC control, high production efficiency
12) The height from the floor to the bottom of the top heating plate is designed according to customer requirements.
13) Daylight design according to customer requirements.
14) Independent control panel.
Competitive price
16) The hot plate is HT200, the surface is processed by surface grinding, the precision of parallelism of board to board is ±0.05mm, and the finish is 1.0μM.
The wires are connected beforehand, and once the power is connected, the machine will start working.

Model	XLB-D1500×2000×2	XLB-D1200×1200×2
Plate size (mm)	1500×2000	1200×1200
Cylinder pressure(T)	1000	500
Working Layer	2	2
Piston Stroke (mm)	1400	1400
Piston Diameter(mm)	400×4set	600
Heating Method	Electric or Steam	Electric or Steam
Hydraulic System Pressure(Mpa)	19.9	17.7
Unit Pressure(N/mm²)	3.33	3.47
Hot plate space(mm)	700	700
About weight(Ton)	35	22
Moving table	equip	equip
Hot plate up speed	≥10mm/s	≥10mm/s
Hot plate down speed	Gravity drop	Gravity drop
Control mode(SIEMENS)	PLC	PLC
