PLC Control System Automatic Rubber Plate Vulcanizing Machine with 1500×1500mm Maximum Product Size
Product Summary
PLC Control System Rubber Plate Vulcanizing Machine Advanced PLC-controlled vulcanizing press designed for manufacturing rubber automotive components, seals, and plugs with precision and efficiency. Machine Applications This rubber and plastic flat vulcanizing machine is engineered for pressing ...
Basic Properties
Place of Origin:
Qingdao
Brand Name:
Beishun
Certification:
ISO/CE
Model Number:
XBL-500*500/2MN
Trading Properties
Minimum Order Quantity:
1set
Price:
Negotiable
Payment Terms:
T/T,L/C
Supply Ability:
30sets
Product Description
PLC Control System Rubber Plate Vulcanizing Machine
Advanced PLC-controlled vulcanizing press designed for manufacturing rubber automotive components, seals, and plugs with precision and efficiency.
Machine Applications
This rubber and plastic flat vulcanizing machine is engineered for pressing various molded products, including rubber and plastic materials, with exceptional performance for thin sheet product manufacturing.
Performance Features
- Four-column integrated mainframe structure with upward pressing mechanism
- Modular design comprising main unit, oil tank, and electrical control box
- Three-way automatic temperature control with adjustable range of 20-200°C
- Automatic constant temperature maintenance and vulcanization time alarm system
Technical Specifications
| Item | Parameter |
|---|---|
| Nominal Clamping Force | 0.25 MN |
| Flat Plate Area | 350×350 mm |
| Hot Plate Spacing | 150 mm |
| Number of Working Layers | 2 layers (customizable) |
| Maximum Hydraulic Pressure | 14.5 MPa |
| Maximum Plunger Stroke | 250 mm |
| Heating Power | 7.2 KW |
| Motor Power | 2.2 KW |
| Overall Dimensions | 1250×550×1420 mm |
| Weight | 1.1 T |
Production Capabilities
The rubber plate vulcanizer serves as essential equipment in rubber product manufacturing, utilizing precise heating and pressure application to facilitate vulcanization reactions that create products with specific mechanical properties.
Industrial Rubber Products
- Seals: Comprehensive range including O-rings, Y-rings, lip seals, gaskets, and flange gaskets for leak-proof sealing in automotive, machinery, and pipeline applications
- Shock Absorbers: Rubber shock absorbers, vibration dampers, buffer blocks, and isolators for automotive, industrial equipment, and construction applications
- Industrial Rubber Sheets/Strips: Oil-resistant, acid-resistant, anti-slip rubber sheets for work surfaces and equipment protection; sealing strips for doors, windows, and cabinets
- Conveyor Belts/Rubber Rollers: Light-duty conveyor systems and corrosion-resistant rubber rollers for printing and packaging machinery
Product Details
Highlight:
PLC Control Rubber Plate Vulcanizing Machine
,1500×1500mm Rubber Vulcanizing Press
,Automatic Rubber Vulcanizer
Working Layer:
1，2，4
Plates Daylight:
300mm
Piston Diameter:
500mm
Weight:
According To Size
Safety Device:
Safety Curtain
Cylinder Stroke:
200mm
Loading Port:
Qingdao, China
Temperature Range:
0-300℃
Pressure Range:
16.8(mpa)
Control System:
PLC
Plunger Diameter:
180-290mm,200 Mm
Maximum Product Size:
1500×1500mm
Auto:
Automatic
Usage:
For Making Bigger Rubber Products
